•Power supply:

2-wire: 12.5-36V DC

4-wire: 24 V AC/DC; 230 V AC 11.4-40V DC / 11.4-28V AC

•Ambient temperature: -30 °C to +70 °C

•Medium temperature: -30 °C to +100 °C

•Pressure: 0.3 - 3 bar

•Measuring range:

0.2 to 25 m for liquids

•Outputs: 4-20 mA, relay, HART, PROFIBUS PA

•Protection: IP 67

•Approvals: ATEX II 1 G EEx ia IIB T6


•2- or 4-wire compact transmitters

•Non-contact level metering

•Narrow 5° beam angle

•Fully temperature compensated

•Excellent signal processing via QUEST+ software

•PP, PVDF, PTFE, stainless steel or foam faced transducers

•Optional field indicator and plug-in programmer/display

•Optional switching relay

•Built-in DataLogger

•Plastic or aluminium housing

•[ HART ]

•[ PROFIBUS PA ]

•Secondary lightning protection

•Explosion-proof models


•Almost any liquids

•Level, volume and open channel flow measurement

•Reliable measurement in challenging applications such as vapour/fume, stirrer, foam with liquids
