UDC1200 和 UDC1700 是基於微處理器的 1/16 DIN 和 1/8 DIN 控制器，

具有高度的功能性和可靠性，而且成本低廉。它們專門用於監測和控制

各種應用中的溫度、壓力和水平，例如環境室、熔爐、烤箱、包裝機以及

塑膠、食品和飲料行業的其他應用。大型且易於閱讀的雙 4 位元顯示器和

觸覺鍵盤使 UDC1200 和 UDC1700 易於配置和使用。其出色的靈活性使您

能夠為任何應用程式配置任何單元，並在需要時進行更改。對於成千上萬

的滿意的 UDC1000/1500 用戶來說，UDC1200/1700 控制器向下兼容現有的

 UDC1000/1500 應用程式和安裝。

Dual display

Two 4-digit displays with 7 LED segments, each configurable for:

 PV and SP (non adjustable)

 PV and SP (adjustable)

 PV and Ramping SP

 PV only

Easier to configure

Two different configuration levels (Configuration mode and set-up mode) provide easy access to parameters. A 4-digit security code prevents unauthorized changes.

Moisture resistant front-face

Meets NEMA 3 / IP65 front-face protection against dust and water.

Universal input

Accept seven different types of thermocouples, RTDs, current and voltage linear inputs. All inputs are configurable as standard.

Universal power supply

The UDC1200 and UDC1700 can operate on any line voltage from 90 Vac to 264 Vac at 50/60 Hz. A 24/48 Vac/dc model is available as an option.

Easy upgrade

 All the option boards are jumper free and detected automatically by the instrument.

Easy output selection

 All the outputs (including the control output) of the instrument can be changed to meet the exact customer’s needs.
