| Description | Information |
|---|---|
| TRU-TUNE®+ Adaptive Control | Yes |
| Agency Approvals | UL®, CSA, CE, RoHS, W.E.E.E., FM, IP66 front seal, SEMI F47-0200, Class 1, Div. 2 |
| Alarms | 4 |
| Ambient Operating Range | -18 to 65°C (0 to 149°F) |
| Communication Protocols |
Bluetooth
Standard Bus
Modbus® TCP
Modbus® RTU
EtherNet/IP™
DeviceNet™
PROFIBUS DP
SAE J1939 CAN Bus
|
| Control/Limit Loops | 2/1 |
| Max Monitor Channels | 2 |
| Max Output | 15A |
| Mounting | 1/32, 1/16, 1/8, 1/4 DIN front panel |
| Output Firing | Zero Cross, Phase Angle |
| Phase Configurations | 1 |
| Profiling | Yes |
| Remote Limit Reset | 1 |
| Display Height | 0.41 in. (11 mm) to 1.60 in. (41 mm) |
| Warranty (Years) | 3 |
