| Input Type |
CT, mA, mV, RTD, TC |
|---|---|
| Panel size (DIN) |
DIN rail |
| PV Accuracy |
<0.1% (with new +/-0.25°C CJC thermocouple compensation) |
| IP Rating |
IP20 |
| Display Type |
Remote |
| Control Types |
On/Off, PID |
| Alarm Types |
Dev, Event, Heater fail, Hi, Lo, Sensor Break |
| Supply Voltage |
24V dc |
| SP Programmer |
8 Programmes, 16 Segments each |
| Real Time Clock |
Day and Time |
| Special Features |
User wiring, Humidity, Load diagnostics |
| Analogue IP/OP In |
32 |
| Analogue IP/OP Out |
8 |
| Digital IP/OP In |
34 |
| Digital IP/OP Out |
32 |
| Digital Comms |
EtherNet/IP, EtherNet/IP Server, Modbus TCP/IP, DeviceNet, Modbus, Profibus |
| Maths Equation |
24 Calculations |
| Combinational Logic |
24 Operations |
| Timers/Counters/Totals |
4 / 2 / 2 |
| PC Configuration |
Graphical wiring |
| Control loops |
16 |
| Control Algorithms |
User wired, Single |
